Description
High Efficiency Variable Frequency Conversion Shield Pump, Multi-Gear, Anti-Condensation Water, and Energy-Saving
This circulating pump is suitable for dielectric circulation in variable flow heating and air conditioning systems and can be controlled by itself via the AUTO version of the operating interface or externally via PWM signal input. Speed control can significantly reduce power consumption. In addition, the performance of the system can be controlled by speed control.
Circulating pumps for HVAC system applications.
Excellent performance, robust construction, optimized for heat pump applications.
Controlled by digital pulse modulated(PWM)low voltage signal(heating curve).
Suitable for antifreeze containing ethylene glycol or ethanol.
Core Advantages & Features
Performance: Ultra-quiet, energy-saving, high head & flow rate; permanent magnet frequency conversion.
Control:
Adaptive control function (suitable for most scenarios).
Built-in proportional pressure differential control (adjusts to system demands).
Optional nighttime automatic speed reduction.
User Experience:
Real-time power consumption display (watts).
Simple setup/operation; alarm signals on control panel.
Safety & Durability:
Overload, dry-run, locked rotor, over/under voltage protection.
BMC plastic stator encapsulation (anti-condensation); thermally conductive silicone-sealed drive board (water/moisture resistance).
Installation: Flexible; compatible with existing systems.
